72V 100Ah Golf Cart Power Batteries

    Model: YD-LFP5120

    Power: 7680Wh

    Battery: LiFePO4

    Rated voltage:76.8V

    Battery pack voltage range:57.5V~84V

    Standard charging current: ≤50A

    Standard discharge current: ≤150A

    Peak current: 450A

    Product Weight: ≈72Kg

    Product Size: 74*32*24.6cm


    Custom: ODM | OEM | Shape | Size | Voltage

    MOQ: 1 pcs


Inquire Now

Tags: LiFePO4 ,


.

Battery

Capacity:

7680Wh

Cell Chemistry:

LiFePO4

Cycle life:

2500 cycles to 80%+ capacity

Management System:

BMS, Over Voltage Protection,Short Circuit Protection

Battery parameter

Rated voltage

76.8V

Battery pack voltage range:

57.5V~84V

Combination:

24S1P

Standard charging current:

≤50A

Standard discharge current:

≤150A

Peak current:

450A

Dimensions

Weight:

72kg (158.73 lbs)

Length:

74cm (29.13in)

Width:

32cm (12.59in)

Height:

24.6cm (9.68in)

General

Warranty:

3+2 Years

Operating Usage Temperature:

-20 - 40℃ (-4 - 104F)

You don't need to confirm, because the battery compartment size of each different brand of golf cart or other electric vehicle is different. We usually customize it according to your battery compartment size, which will fully meet your battery compartment capacity and maximize the battery capacity. I believe you will like the final product.

Of course, professional protection boards and temperature sensors are installed inside, and the professional system prevents overcharging, over-discharging and temperature loss. It can be connected to a digital display screen, allowing you to monitor your battery status at any time. And it uses very safe lithium iron phosphate batteries, which have a high number of cycles and are safer than lithium batteries.

Yes, individual batteries can also be customized, but we must tell you that customized products cannot be returned or exchanged, and you must provide us with detailed data to ensure the correctness of the customized products.
